Model |
DS-2CD1043G0-I |
Image Sensor |
1/3 inch Progressive Scan CMOS |
Min. Illumination |
Color: 0.01 Lux @(F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON) |
Shutter Speed |
1/3 s to 1/100,000 s |
Slow Shutter |
Yes |
Day & Night |
IR Cut Filter |
WDR |
DWDR |
Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 180°, rotation: 0° to 360° |
IR Range |
Up to 30 m |
Lens |
Lens Type |
2.8 mm, 4 mm, 6 mm |
Aperture |
F2.0 |
FOV |
2.8 mm, horizontal FOV 100°, vertical FOV 55°, diagonal FOV 117°
4 mm, horizontal FOV 77°, vertical FOV 42°, diagonal FOV 88°
6 mm, horizontal FOV 51°, vertical FOV 28°, diagonal FOV 58° |
Lens Mount |
M12 |
Video |
Max. Resolution |
2560 × 1440 |
Video Compression |
Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG |
Video Bit Rate |
32 Kbps to 8 Mbps |
Network |
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 UDP, Bonjour |
Simultaneous Live View |
Up to 6 channels |
API |
ONVIF (PROFILE S), ISAPI, SDK |
User/Host |
Up to 32 users, 3 levels: administrator, operator and user |
Interface |
Communication |
1 RJ45 10M/100M self-adaptive Ethernet port |
Smart Feature-set |
Basic Event |
Motion detection, video tampering alarm, exception (illegal login) |
Linkage Method |
Upload to FTP, notify surveillance center, send email |
Region of Interest |
1 fixed region for main stream |
Image |
Image Enhancement |
BLC, HLC, 3D DNR |
Image Setting |
Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser |
Day/Night Switch |
Day/Night/Auto/Schedule |
S/N Ratio |
> 50dB |
General |
General Function |
Anti-flicker, heartbeat, mirror, privacy mask |
Power Supply |
12 VDC ± 25%, 5.5 mm coaxial power plug
PoE (802.3af, class 3)
|
Material |
Front cover: metal, back cover: plastic |
Operating Conditions |
-30°C to +60°C, Humidity 95% or less (non-condensing) |
Protection |
IP67 |
Dimensions |
Camera: Ø 70 mm × 172.7mm ( 2.7" × 6.8")
With package: 216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
|
Weight |
Camera: approx. 280 g (0.62 lb.)
With package: approx: 530 g (1.17 lb.)
|
