Camera |
Image Sensor |
1/2.8 inch Progressive Scan CMOS |
Signal System |
PAL/NTSC |
Min. Illumination |
Color: 0.005 Lux @ (F1.2, AGC ON), 0 Lux with IR
Color: 0.009 Lux @ (F1.6, AGC ON), 0 Lux with IR |
Slow shutter |
Support |
Shutter time |
1/3 s to 1/100,000 s |
Lens |
2.8 mm/4 mm/6 mm/8 mm/12 mm fixed lens, optional |
Lens Mount |
M12 |
Adjustment Range |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
Day& Night |
IR cut filter with auto switch |
Wide Dynamic Range |
120 dB |
Digital noise reduction |
3D DNR |
Focus |
Fixed |
Compression Standard
|
Video Compression |
H.265+/H.265/H.264+/H.264/MJPEG |
Video bit rate |
32Kbps~16Mbps |
Triple Streams |
Yes |
|
Max. Image Resolution |
1920 x 1080 |
Image Enhancement |
BLC / 3D DNR / ROI / HLC |
Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness and white balance adjustable by client software or web browser |
KING |
Support 1 fixed region for main stream and sub stream separately |
Day/Night Switch |
Day/Night/Auto/Schedule |
Network
|
Network Storage |
microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
Alarm Trigger |
Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error |
Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
General Function |
One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering |
System Compatibility |
ONVIF (Profile S, Profile G), ISAPI |
Interface
|
Communication Interface |
1 RJ45 10M / 100M Ethernet interface |
On-board storage |
Built-in Micro SD/SDHC/SDXC slot, up to 128 GB |
Smart Feature-set
|
Behavior Analysis |
Line crossing detection, Intrusion detection, Unattended baggage detection, Object removal detection |
Line Crossing Detection |
Cross a pre-defined virtual line |
Intrusion Detection |
Enter and loiter in a pre-defined virtual region |
Unattended Baggage |
Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
Object Removal |
Objects removed from the pre-defined region, such as the exhibits on display |
Exception Detections |
Scene change detection |
Detection/Recognition |
Face Detection |
General
|
Operating Conditions |
-30 °C ~ 60 °C (-22 °F ~ 140 °F) |
Power Supply |
12 VDC ± 25%, PoE (802.3af Class3) |
Power Consumption |
12 VDC ± 25%, 5W
PoE(802.3af, class 3), 6.5W |
Weather Proof |
IP67 |
IR Range |
Up to 30m |
Dimensions |
Φ70 × 155.03 mm |
Weight |
410 g |
