| Hardware specifications |
| Radio |
Dual-stream dual-band |
| Protocol |
Concurrent 802.11b/g/n/ac |
| Operating Bands |
802.11b/g/n ：2.4G ~ 2.4835GHz
802.11a/n/ac ： 5G：5.150～5.350GHz，5.47～5.725，5.725～5.850GHz
(Note: The operating bands vary according to different countries) |
| Antenna |
PCB antenna |
| Spatial Streams |
2.4G: 2 Spatial Streams,2x2 MIMO
5G: 2 Spatial Streams,2x2 MIMO |
| Max Throughput |
2.4G: up to 400Mbps
5G: up to 866.7Mbps |
| Modulation |
OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps
MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM and 256QAM |
| Receive Sensitivity |
11b：-97dBm(1Mbps) ，-92dBm(5Mbps) ，-89dBm(11Mbps)
11a/g：-94dBm（6Mbps），-85dBm（24Mbps），-82dBm（36Mbps），-76.5dBm（54Mbps）
11n：-93.5dBm@MCS0，-74dBm@MCS7，-74dBm@MCS15
11ac：HT20：-92.5dBm（MCS0）, -68.5dBm（MCS8）
11ac：HT40：-89dBm（MCS0）, -64dBm（MCS9）
11ac：HT80：-86dBm（MCS0）, -60.5dBm（MCS8） |
|
Maximum Transmit Power
|
20dBm (adjustable) |
|
Adjustable Power
|
1dBm |
|
Dimensions
|
86*86*29.3 |
|
Weight
|
<0.25kg |
| Service Ports |
Front：
1 10/100Mbps Ethernet portRear：
1 10/100Mbps PoE Ethernet port |
| Management Port |
N/A |
| LED Indicator |
Support |
| Power Supply |
Support 802.3af power supply |
| Power Consumption |
＜8W |
| Environment |
Operating temperature: 0°C～40°C |
| Storage temperature: -40°C～70°C |
| Operating humidity: 5％～95％（non-condensing） |
| Storage humidity: 5％～95％（non-condensing） |
| Installation |
86mm wall plate installation |
| IP Rating |
IP41 |
| Safety Standard |
GB4943, IEC 60950-1 |
| EMC Standard |
GB9254，EN301 489，EN50155，EN50121，EN55032，EN61000，EN55035 |
| Vibration Standard |
IEC61373 |
| Radio Standard |
SRRC certification |
| Software Features |
| Operating Mode |
AP mode and routing mode |
| WLAN |
Maximum number of clients: 110 |
| Recommended number of clients: 24 (8 at 2.4GHz, 16 at 5GHz) |
| Up to 8 SSIDs |
| Support SSID hiding
Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID |
| SSID-based and radio-based STA limit |
| Support Layer 2 user isolation |
| Roaming |
Support Layer 2 and Layer 3 roaming |
| Security |
Support PSK authentication |
| Support static blacklist and whitelist |
| Support WPA (TKIP), WPA2 (AES), and WPA-PSK data encryption |
| Routing |
Support static IP address, DHCP, PPPoE Dial Up |
| Management and maintenance |
Support unified networking of all network equipment
Support local or remote management with Ruijie Cloud app
Support local management with web
Support remote management with Ruijie Cloud platform |
| Platform management features |
Automatic RF adjustment via the platform |
| Unified configuration via the platform |
| Unified monitoring via the platform |
