CPU |
Intel® Xeon® W-1270 8-core 3.4 GHz processor (boost up to 5.0 GHz) |
CPU Architecture |
64-bit x86 |
Floating Point Unit |
|
Encryption Engine |
(AES-NI) |
Hardware-accelerated Transcoding |
|
System Memory |
64 GB UDIMM DDR4 ECC (4 x 16 GB) |
Maximum Memory |
128 GB (4 x 32 GB) |
Memory Slot |
4 x Long-DIMM DDR4
For dual-DIMM configurations, you must use a pair of identical DDR4 modules. |
Flash Memory |
5GB (Dual boot OS protection) |
Drive Bay |
Front: 24 x 2.5-inch SATA 6Gb/s, 3Gb/s
Rear: 6 x 2.5-inch SATA 6Gb/s, 3Gb/s
The system is shipped without HDD.
For the HDD compatibility list, please visit https://www.qnap.com/compatibility/ |
Drive Compatibility |
2.5-inch bays:
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives |
Hot-swappable |
|
SSD Cache Acceleration Support |
|
2.5 Gigabit Ethernet Port (2.5G/1G/100M) |
4 |
5 Gigabit Ethernet Port (5G/2.5G/1G/100M) |
Optional via an adapter |
10 Gigabit Ethernet Port |
Optional via an adapter |
Wake on LAN (WOL) |
Only the 2.5GbE port |
25 Gigabit Ethernet Port |
2 |
Jumbo Frame |
|
PCIe Slot |
3
Slot 1: PCIe Gen3 x8 or x4
Slot 2: PCIe Gen3 x4
Slot 3: PCIe Gen3 x4
*Slot 1 is preinstalled with a 25GbE network adapter. Please reserve this slot for the 25GbE adapter for the best performance.
**Slot 1 provides the width of PCIe Gen3 x8 when Slot 2 is not in use, and provides the width of PCIe Gen3 x4 when Slot 2 is in use. |
USB 3.2 Gen 2 (10Gbps) Port |
2 x Type-C USB 3.2 Gen 2 5V/3A 10Gbps
2 x Type-A USB 3.2 Gen 2 5V/1A 10Gbps |
HDMI Output |
1, HDMI 1.4b (up to 4096 x 2160 @ 30Hz) |
Form Factor |
Rackmount |
LED Indicators |
HDD, Status, 10 GbE, LAN, storage expansion port status |
Buttons |
Power, Reset |
Dimensions (HxWxD) |
3.48 × 18.94 × 20.28 inch |
Weight (Net) |
27.03 lbs |
Weight (Gross) |
39.4 lbs |
Operating temperature |
0 – 40°C (32°F – 104°F) |
Relative Humidity |
5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F) |
Power Supply Unit |
550W(x2), 100-240V |
Power Consumption: HDD Sleep Mode |
129.57 W |
Power Consumption: Operating Mode, Typical |
261.81 W
Tested with drives fully populated. |
Fan |
3 x 60mm, 12VDC |
Sound Level |
53 db(A) |
System Warning |
Buzzer |
Max. Number of Concurrent Connections (CIFS) |
10,000 |
